One set of these tubes contains the fluid that must be either heated or cooled. The second fluid runs over the tubes that are being heated or cooled so that it can either provide the heat or absorb the heat required. A set of tubes is called the tube bundle and can be made up of several types of tubes: plain, longitudinally finned, etc. There are several thermal design features that are to be taken into account when designing the tubes in the shell and tube heat exchangers.

Process liquid or gas cooling Process or refrigerant vapour or steam condensing Process liquid, steam or refrigerant evaporation Process heat removal and preheating of feed water Thermal energy conservation efforts, heat recovery Compressor, turbine and engine cooling, oil and jacket water Hydraulic and lube oil cooling. However, it is more likely for the heat exchanger to foul up faster and the small size makes mechanical cleaning of the fouling difficult.

To prevail over the fouling and cleaning problems, larger tube diameters can be used. Thus to determine the tube diameter, the available space, cost and the fouling nature of the fluids must be considered. Thus, typically there is an aim to make the heat exchanger as long as physically possible whilst not exceeding production capabilities.

However, there are many limitations for this, including the space available at the site where it is going to be used and the need to ensure that there are tubes available in lengths that are twice the required length so that the tubes can be withdrawn and replaced. In many cases, plate heat exchangers are oversized simply to reduce the pressure drop for the secondary fluid.

Basics of Shell & Tube Heat Exchangers

On existing plant, an indication of actual load may be obtained if the flow and return temperatures and the pumping rate are known. Shell and tube heat exchangers and plate heat exchangers are typical examples of flow type applications. Therefore, when determining the steam consumption for these applications, Equation 2.

The start-up load may be ignored if it occurs rarely, or if the time taken to reach full-load output is not too important. Heat exchangers are more often sized on the full running load, with the possible addition of safety factors. Heat losses are rarely taken into account with these flow type applications, as they are significantly less than the full running load. Shell and tube heat exchangers are usually lagged to prevent heat loss, and to prevent possible injury to personnel.

Plate heat exchangers tend to be more compact and have a much smaller surface area exposed to the ambient air, in relation to the size of the unit.
